Corner LED Aluminum Profiles for Angled Lighting
Corner LED Profiles | Compact to Large Sizes | Custom Manufacturing Support
Browse All Corner LED Aluminum Profiles
Showing 1–12 of 14 results
-
-
Corner LED Aluminum ProfileLSH153 Corner LED Aluminum Profile, 20×20mm, for 8mm LED Strips
Read more -
Corner LED Aluminum ProfileLSH199 Corner LED Aluminum Profile 25x25mm for 15mm LED Strips
Read more -
Corner LED Aluminum ProfileLSH199 Corner LED Aluminum Profile 30x30mm for 15mm LED Strips
Read more -
Corner LED Aluminum ProfileLSH199B Corner LED Aluminum Profile 30x30mm for 15mm LED Strips
Read more -
-
Corner LED Aluminum ProfileLSH431 Corner LED Aluminum Profile, 20×20mm, for 8mm LED Strips
Read more -
-
-
-
-
What Is a Corner LED Aluminum Profile?
A corner LED aluminum profile is a housing that positions a compatible LED strip or rigid LED bar at an angle in a corner installation. A fitting diffuser covers the light source and completes the visible light line. With suitable thermal contact, the aluminum body can help transfer heat from the LED strip.
These profiles suit cabinet corners, wardrobes, display cases and shelving. Choose the cross-section according to the available space, internal strip clearance, diffuser shape and desired lighting direction.
Explore Our Corner LED Aluminum Profile Collection
Compact 8–13mm Corner LED Profiles
Models: LSH56, LSH57, LSH006 and LSH407.
Compact housings suit furniture details with limited installation space. LSH56 is 8×8mm and LSH57 is 10×10mm; LSH006 and LSH407 are listed as 13×13mm. Listed strip widths range from 3mm to 5mm, depending on the model. Check the internal drawing and complete strip assembly before ordering.
16–20mm Corner LED Profiles
Models: LSH58, LSH58B, LSH60, LSH59, LSH61, LSH153 and LSH431.
Compare these profiles for cabinet, shelf and display lighting with listed 8mm or 10mm LED strips. LSH58 and LSH58B share a listed 16×16mm size but use different structures.
25–30mm Corner LED Profiles
Models: LSH199 (25×25mm), LSH199 (30×30mm) and LSH199B (30×30mm).
LSH199 is available in the listed 25×25mm and 30×30mm versions, while LSH199B is listed as 30×30mm. These models list 15mm strip or rigid bar compatibility. Compare diffuser contours, internal mounting surfaces and accessory fit; a larger external size alone does not establish a permissible LED power rating.
How to Choose the Right Corner LED Aluminum Profile
Follow these five checks before confirming a profile model.
1. Check the External Dimensions
Measure both sides of the installation corner and check nearby doors, hinges and shelf supports. Compare the actual external dimensions and fixing arrangement against the model-specific drawing. Allow room for the diffuser, cable exits and installation tools.
2. Compare Cross-Section Designs
Profiles with identical external dimensions can have different channel shapes, mounting edges and diffuser positions. Choose using the real technical drawings, not the model suffix alone.
3. Confirm Light Direction and Glare
Position a working sample in the intended corner. Check how the angled profile directs light onto the worktop, shelf or display. Inspect reflections from glass and glossy surfaces, and avoid placing the LED source directly in the normal viewing line.
4. Check LED Strip Compatibility
External profile width does not determine compatible LED strip width. Check internal channel dimensions, LED strip PCB width, solder joints, connectors and available clearance. Test the final strip and diffuser combination where possible.
5. Review Installation Requirements
Confirm the fixing method, matching clips and end caps, cable routing and diffuser removal space. Test the LED strip at its intended power in the actual mounting environment. Agree on the accessory scope before ordering.
Technical Specifications and Size Comparison
| Model | Overall dimensions | Listed strip / rigid bar width |
|---|---|---|
| LSH56 | 8×8mm | 3mm |
| LSH57 | 10×10mm | 5mm |
| LSH006 | 13×13mm | 3mm |
| LSH407 | 13×13mm | 5mm |
| LSH153 | 20×20mm | 8mm |
| LSH431 | 20×20mm | 8mm |
| LSH58 | 16×16mm | 8mm |
| LSH58B | 16×16mm | 8mm |
| LSH60 | 18×18mm | 10mm |
| LSH59 | 18×18mm | 10mm |
| LSH61 | 19×19mm | 10mm |
| LSH199 | 25×25mm | 15mm |
| LSH199 | 30×30mm | 15mm |
| LSH199B | 30×30mm | 15mm |
LSH153 dimension note: The product is listed as 20×20mm. Its product-page specification retains the earlier 19×19mm nominal description and 19.9×19.9mm drawing dimensions. Confirm the approved cross-section before ordering.
Common Technical Specifications
| Item | Specification |
|---|---|
| Product Name | Corner LED Aluminum Profile |
| Installation Type | Corner mounting |
| Housing Colors | Silver / Black / White |
| Diffuser | Opal / Frost/Clear and Black PC cover |
| Alloy and Finish Process | Anodized |
| Lengths and Customization | 1m,2m,2.5m,3m and order requirements |
| Accessories | End caps and Clips |
| Packaging | PE bag, Carton |
| Warranty | 5 years |
Technical Note: Confirm the approved cross-section, full LED source dimensions, cover fit and mounting arrangement before ordering.
What Does 45° Mean?
In this collection, 45° describes the angled corner profile arrangement. It does not specify the optical beam angle of a complete light fitting. Actual light distribution depends on the LED source, diffuser, profile geometry and installation orientation. Check a sample to confirm illumination and glare at the intended viewing position.
Installation Options and Project Considerations
Check the Corner and Fixing Surface
Check the angle, flatness and available space on both mounting surfaces. Confirm clearance around doors, hinges and shelf supports. Choose the exact model and matching mounting accessories before drilling or cutting furniture.
Plan the Lighting Direction
Identify the surface to illuminate and the normal viewing position. Rotate a sample into the intended orientation and check for direct glare, shadows and reflections. The housing angle alone does not guarantee a particular optical beam.
Check the Diffuser and LED Strip
Test the actual LED strip and diffuser together along a complete sample. Check internal clearance, cover engagement, visible LED dots and color appearance. Covers and end caps are not necessarily interchangeable between similar model sizes.
Allow for Wiring and Maintenance
Plan cable exits, connectors, drivers and maintenance access before fixing the profile. Allow sufficient clearance to remove the diffuser. For long runs, check the electrical design and potential LED strip voltage drop.
Applications of Corner LED Aluminum Profiles
Engineering-focused guidance for lighting manufacturers, project contractors and wholesale buyers.
Under-Cabinet Lighting
Use an angled arrangement to direct light toward the worktop or backsplash. Compare XT58 and XT58B for listed 8mm strips, or XT59 and Lvsen 18×18 for listed 10mm strips. Confirm illumination and glare with a working sample.
Wardrobes and Compact Furniture
LSH56 and LSH57 offer compact 8×8mm and 10×10mm external sizes. TP006 and XT407 provide additional compact layouts. For 8mm LED strips, compare LSH153, LSH431, XT58 and XT58B. Check cable exits and clearance around furniture hardware.
Display Cabinets and Shelving
Compare cover shapes and installation positions to illuminate merchandise while limiting visible LED dots and glass reflections. For listed 15mm strips, review SDXT199, XT199 and XT199B, then verify the complete assembly.
Interior Corners and Commercial Projects
Corner profiles may suit interior wall-to-ceiling junctions and commercial furniture details where the cross-section and fixing method fit the project. Confirm light direction, service access and the complete assembly; these listings do not establish a waterproof rating.
Engineering-focused guidance for lighting manufacturers, project contractors and wholesale buyers.
Not every project fits a standard aluminum profile. Unionopto can review your technical requirements and discuss customization based on feasibility, tooling and order quantity.
Profile Dimensions and Structure
Share your required width, height, mounting opening or cross-section drawing. We can review whether an existing profile is suitable or whether a modified design or new extrusion die is needed.
Aluminum Surface Finish
Silver anodized is a common standard finish. Black, white and other finishes can be discussed according to the project and production requirements.
PC Diffusers and Cover Designs
Compare opal and frosted PC covers and the available flat or rounded contours. Confirm fit with the exact profile model. Light transmission and visible LED dots depend on the selected cover and LED source; approve a sample before bulk production.
Lengths, Accessories and Drawings
Provide the required lengths, quantities, mounting accessories, CAD drawings or physical samples so that feasibility, sampling and production arrangements can be reviewed.
Quality Checks Before Bulk Purchasing
Profile Dimensions and Cross-Section
Check the approved drawing against the profile’s external dimensions, internal LED strip channel, diffuser fitting and mounting features.
Strip Fit and Thermal Performance
Check the complete strip width, coating, solder joints and connectors against the internal channel. Test thermal contact and operating temperature at the intended power. Do not treat external profile dimensions as a verified wattage rating.
PC Diffuser Fit
Check the diffuser along the full sample length with the intended LED strip. Inspect cover engagement, visible dots, glare and removal clearance after installation.
Finish, Accessories and Packaging
Verify surface finish, accessories, packing method, product lengths and shipping protection before mass production. For a new model, sample approval and a confirmed technical drawing are recommended.
Frequently Asked Questions
No. The term refers to the angled profile arrangement. The LED source, diffuser and installation determine the actual light distribution.
Start with the listed strip width in the comparison table. Then check the internal drawing and include any coating, wiring and connectors in your clearance calculation.
A COB strip may be considered if its complete width, height and thermal requirements suit the selected model. Verify fit and lighting appearance with a sample.
Not necessarily. LED spacing, the distance to the cover, diffusion characteristics and viewing distance all affect visible dots. Test the actual strip and cover together.
Yes, some items we can provide waterproof protection. Such as LSH 153 20x20mm the LED strips hide into a sealed PC cover.
The listings show silver, black and white housing options. Ask for the available lengths and the exact finish process for the selected model.
Send the model or cross-section requirements, LED strip dimensions, required lengths, quantity, housing color, cover preference and installation details. Include drawings or photos where available.
Request a Quote for Corner LED Aluminum Profiles
Sourcing corner LED aluminum profiles for furniture lighting, an interior project or a wholesale range? Share your requirements so our team can review suitable models and customization options.
Please send your preferred model or cross-section, LED strip dimensions, intended power, required lengths, quantity, housing finish, diffuser preference and mounting details. Include a CAD drawing or installation photo where available.
For an accurate quotation, include the model, quantity, cut lengths, finish and required accessories with your project details.
Available lengths, finish processes, accessory scope, tooling requirements and lead time will be confirmed for your order.
Send Your Project Requirements
